SUI Vertical Lift Transaction Drive-up/Walk-up Window | Manual and Electric Options

SKU CSE-QS-SUI-200-2430-1/4-C

Usually Ships Within:

Original price $2,100.00 - Original price $8,050.00
Original price
$2,100.00
$2,100.00 - $8,050.00
Current price $2,100.00
Color | Size: Clear | 24” (w) x 30” (h)
Automation | Communication: Manual
Glass: 1/4" Tempered
Custom Quote

Looking up.


Our vertical lift transaction windows are the perfect pass-through windows for multiple service areas, walk-up service counters, and areas with limited space. These industrial grade commercial windows are weather sealed and designed for heavy use day in and day out. Comes in three standard sizes with custom sizes available upon request.

The model SUI200 is a manually operated window with a 7" stainless steel handle and will remain open at the height of your choice.

The model SUI100 is a hands-free automated window with a built-in optic sensor that will detect your presence and open and close automatically.

    SUI Series vertical lift window drive thru Covenant security equipmentSUI Series vertical lift window drive thru Covenant security equipmentQuikserv SUI vertical lift transaction drive thru window Covenant Security Equipment

    Tech Specs

    Details

    *No speak thru available on 1" insulated and Bullet Resistant units.

    *Not built for sterilized environment.

    SUI-100
    Electric automatic window.
    Logic lock options:

    • Standard: Allows the ‘hands-free’ operation of the window through the optic sensor.
    • Peak Period: Opens the window and keeps it open until this mode is disengaged.
    • Night Latch: Disengages the optic sensor and engages a plunger lock to secure the window.

    SUI-200
    Manually operated window.

    Dimensions

    24" (w) x 30" (h) | Service opening: 20" (w) x 8-5/8" (h)
    24" (w) x 48" (h) | Service opening: 20" (w) x 17-3/4" (h)
    36" (w) x 48" (h) | Service opening: 32" (w) x 17-5/8" (h)

    Custom size options:
    Minimum
    Electric: 24" (w) x 30" (h)
    Manual: 24" (w) x 30" (h)
    Maximum
    Electric: 40" (w) x 50" (h)
    Manual: 40" (w) x 50" (h)

    Glazing Specifications

    1/4" Tempered Glass

    Thickness: .25"
    Weight (lbs/sq ft.): 2.87
    Transmittance: visible 89 / solar 81
    Reflectance: visible out 8 / visible in 8 / solar out 8
    U-value: winter night 1.03 / summer day 0.93
    SHGC: 0.84

    1/4 Tempered Glass Specification

    Level 1 Glass

    Ballistic Protection: 9mm UL 752
    Thickness: 1.25"
    Weight (lbs/sq ft.): 7.7
    Transmission: >90%
    Haze: <1%
    Abrasion resistance (coated): 0.2 to 2.0 (%haze change)
    Abrasion resistance (uncoated): 14 (%haze change)
    Tensile strength: 9,500 psi
    Tensile modulus: 400,000 psi
    Flex modulus: 400,000 psi
    Burn rate: 1.2" min
    Smoke density: max 8%, rating 5%
    Auto ignition temperature: 870 F

    Level 1 Acrylic Glass Specification

    Level 3 Glass

    Ballistic Protection: .44 magnum UL 752
    Thickness: 1.25"
    Weight (lbs/sq ft.): 7.7
    Transmission: >85%
    Haze: <1.5%
    Abrasion resistance (coated): 0.2 to 2.0 (%haze change)
    Abrasion resistance (uncoated): 14 (%haze change)
    Tensile strength: 9,400 psi
    Tensile modulus: 400,000 psi
    Flex modulus: 400,000 psi
    Burn rate: .23" min
    Smoke density: max 65%, rating 49%
    Auto ignition temperature: 870 F

    Level 3 Acrylic Glass Specification

    Downloads

    Installation (Automatic)

    Installation (Manual)

    Manual

    2430 Three-side view
    2448 Three-side view
    3648 Three-side view

    Electric

    2430 Three-side view
    2448 Three-side view
    3648 Three-side view


    Warranty

    Covered by our 12-month Warranty
